Photos Of General Instrument HDD-1000 High Definition Decoder

[wallyhts]

Hi,



[Kb Cool]

I used to have one of those. But, the peice of junk had the dreaded StarzHD drop-out problem.

P.S. resize your pictures



[tvropro]

Nice pictures



[Mr Tony]

Please use the attachment option next time to make the pics thumbnails. Then folks can click to see the full size

Thanks!



[wallyhts]

I used to have one of those. But, the peice of junk had the dreaded StarzHD drop-out problem.

P.S. resize your pictures

What receiver were you using?



[wallyhts]

Please use the attachment option next time to make the pics thumbnails. Then folks can click to see the full size

Thanks!

Thanks for doing that will do on next post.



[Kb Cool]

What receiver were you using?

DSR 920 4DTV.



[wallyhts]

Do you know the pinout from the MMAP Port to HSI input on HDD-1000?

I also have a DSR 920.

Thanks



[Kb Cool]

Do you know the pinout from the MMAP Port to HSI input on HDD-1000?

I also have a DSR 920.

Thanks

No, i just cut the 3.5mm head phone plug off a MMapp cable i already had. Stripped and connected the 2 wires to the HSI in. I think the pin out is around the web somewhere.


I googled this post from Lee Richardson. http://www.tomshardware.com/forum/40439-25-hdd200-mmap-data-cable-pinout



[wallyhts]

Thanks kbghdg,

I will try DB9
4 - HS+
9 - HS-
5 - Gnd

If that does not work i will switch 4 and 9.



[Kb Cool]

Thanks kbghdg,

I will try DB9
4 - HS+
9 - HS-
5 - Gnd

If that does not work i will switch 4 and 9.

Yes, that should work. If i remember correctly that thing had relays in it that'll start clicking when not on a HD channel. I used BNC to RCA adapters to send the signal into my tv. Also, the picture wasn't perfectly centered on the display. I did get it for cheap though and i sold it cheap fast.



[eurosport]

I have this decoder and use it with my Digitrans DTE-7150 commercial box.
