Elevation / Declination Azimuth diagram

pacificrim

pacificrim

Thread Starter
SatelliteGuys Pro
Oct 5, 2008
1,174
1,093
West Coast Canada
I just wanted thank whoever posted this image here originally

Track


It really helped me tweak my dish for the whole arc Ku after I just did some over adjusting. Specifically, I didn't adjust anything else except Declination once I knew saw the picture and compared my situation. CBand was not affected - strictly Ku

I used my elevation actuator to peak my Due South sat at 125w and then compared it to peaking other sats 10-20 degrees on either side and determined it was a bit over on declination. Crazy what a millimetre or two out of whack will do to Ku. Thanks for these resources! I probably would have adjusted (wrestled) my Azimuth if not for this pic. Cheers!











I

B

Brct203

SatelliteGuys Pro
Dec 24, 2016
1,276
1,267
Connecticut
agreed! Once this diagram is understood, aligning a dish is no longer a blind recipe, but something that makes geometrical sense!

johnnynobody

johnnynobody

Star Trek fan
Pub Member / Supporter
Aug 2, 2009
6,992
1,351
USA
Probably should post a clearer image in a permanent location.

  • Like
Reactions: Elsguy
mr_rye89

mr_rye89

SatelliteGuys Guru
Pub Member / Supporter
Jul 5, 2020
132
127
Central New Mexico
Breddy gud! I’m probably too far west I can’t get 87w, but I get 127w and 107 is zenith for me

Titanium

Titanium

AI6US
Lifetime Supporter
May 23, 2013
7,373
8,503
Meadow Vista, Northern California
Breddy gud! I’m probably too far west I can’t get 87w, but I get 127w and 107 is zenith for me
My system easily tracks 87w - 139w. Could track further East if the roof peak was not blocking the horizon. At the previous business warehouse, 15 miles West of here, tracked 55w - 139w. Be sure the feedhorn is centered on the parabola then fine tune the elevation and declination settings.

No reason a polar mount can't track the entire arc, unless the dish parabola and/or mount is damaged or incorrectly assembled. .

  • Like
Reactions: mr_rye89 and clucas
pacificrim

pacificrim

Thread Starter
SatelliteGuys Pro
Oct 5, 2008
1,174
1,093
West Coast Canada
We are entering the next solar outage period - starting around October 8th or so. With the sun running on the same arc as the geostationary satellites for about a week, it is a great time to see which satellites are in your view and what might be blocking certain positions.

I also have a clear view of 87-139 and when there was at sat at 83w I went outside at 8am to see what was in its way - yup neighbour's tree.

  • Like
Reactions: FTA4PA
pacificrim

pacificrim

Thread Starter
SatelliteGuys Pro
Oct 5, 2008
1,174
1,093
West Coast Canada
I could barely read it when I was using it. It is a transparent GIF and depending on the background it is legible or not. It works in this post for me but if I open the GIF as a file on my mac it is pixelated garbage.

I'm going to make screen shot and resave it

It really did save me a bunch more time wasting wrench turning but broke my brain trying to read it
Probably should post a clearer image in a permanent location

FTA4PA

FTA4PA

Satellite Guys Family
Lifetime Supporter
Nov 13, 2013
5,570
3,479
Central Pennsylvania
I think I posted the original image. It actually came from here:
Their site has a copyright of 2013-2021. That image existed long before they used it. It is on this page saved from 2001 at the Wayback Machine from the now defunct geo-orbit site.


I shared that page myself back in 2014 after someone (can't remember who but thank you) shared it with me after I joined in 2013. It has definitely been helping people for a long time. :)
